| Kuantitas: | |
|---|---|
| Milik | NBR | Fkm | Neoprene | EPDM | Sillicon |
| Kepadatan | 1,5 ± 0,1g/cm3 | 2,0 ± 0,1g/cm3 | 1,5 ± 0,1g/cm3 | 1,4 ± 0,1g/cm3 | 1,25 ± 0,1g/cm3 |
| Kekerasan | 65 ± 5 (pantai A) | 70 ± 5 (pantai A) | 65 ± 5 (pantai A) | 65 ± 5 (pantai A) | 50 ± 5 (pantai A) |
| Kekuatan tarik | ≥3.5mpa | ≥8MPA | ≥3.5mpa | ≥5mpa | ≥5.5mpa |
| Perpanjangan saat istirahat | ≥280% | ≥250% | ≥280% | ≥250% | ≥300% |
| Set kompresi | ≤0,8% (70 ℃ x 22 jam) | ≤0,7% (70 ℃ x 22 jam) | ≤0,7% (70 ° C x 22 jam) | ≤0,7% (70 ° C x 22 jam) | ≤0,7% (70 ° C x 22 jam) |
| Suhu kerja. | -50 ° C - 120 ° C. | -20 ° C - 200 ° C. | -40 ° C - 120 ° C. | -50 ° C - 150 ° C. | -55 ° C - 230 ° C |
| Max. Tekanan | 1.7Mpa | 4Mpa | 1.7Mpa | 2mpa | 2mpa |
| Ketebalan | 1.0mm, 1.5mm.2.0mm, 3.0mm) | ||||
| Ukuran lembar | 1.0mx1.0m, 1.5mx1.5m | ||||
| Milik | NBR | Fkm | Neoprene | EPDM | Sillicon |
| Kepadatan | 1,5 ± 0,1g/cm3 | 2,0 ± 0,1g/cm3 | 1,5 ± 0,1g/cm3 | 1,4 ± 0,1g/cm3 | 1,25 ± 0,1g/cm3 |
| Kekerasan | 65 ± 5 (pantai A) | 70 ± 5 (pantai A) | 65 ± 5 (pantai A) | 65 ± 5 (pantai A) | 50 ± 5 (pantai A) |
| Kekuatan tarik | ≥3.5mpa | ≥8MPA | ≥3.5mpa | ≥5mpa | ≥5.5mpa |
| Perpanjangan saat istirahat | ≥280% | ≥250% | ≥280% | ≥250% | ≥300% |
| Set kompresi | ≤0,8% (70 ℃ x 22 jam) | ≤0,7% (70 ℃ x 22 jam) | ≤0,7% (70 ° C x 22 jam) | ≤0,7% (70 ° C x 22 jam) | ≤0,7% (70 ° C x 22 jam) |
| Suhu kerja. | -50 ° C - 120 ° C. | -20 ° C - 200 ° C. | -40 ° C - 120 ° C. | -50 ° C - 150 ° C. | -55 ° C - 230 ° C |
| Max. Tekanan | 1.7Mpa | 4Mpa | 1.7Mpa | 2mpa | 2mpa |
| Ketebalan | 1.0mm, 1.5mm.2.0mm, 3.0mm) | ||||
| Ukuran lembar | 1.0mx1.0m, 1.5mx1.5m | ||||
